WiFi Temperature Probe Data Logging Sensor – EL-WiFi-TP

The EL-WiFi-TP sensor measures the temperature of the environment in which the probe is situated. Data is transmitted wirelessly via a WiFi network to a PC and viewed using a free software package. During configuration the sensor will search for an existing wireless network whilst physically connected to the PC. It can then be placed anywhere within range of the network. If the sensor temporarily loses connectivity with the network, it will log readings until it is able to communicate again with the PC application (max 120 days at 10 second sample interval). The range of the sensor can be increased by using WiFi extenders.

The probe can be used in a wide range of temperature situations e.g. manufacturing processes, cold storage and hot storage.

This EL-WiFi-TP is a low powered battery device. When configured using typical sampling periods (e.g. once every 60 seconds) the sensor will operate for over one year. The battery can then be recharged via a PC or USB +5V wall adapter using the USB lead provided.

Initial configuration of the data logger is done with Lascar’s EL-WIN-WiFi software running on Windows (compatible with 32-bit and 64-bit versions of Windows 7, 8 and 10). EasyLog Cloud gives access to each data logger and data collected from any internet-enabled device including smartphone, tablet or computer. Change data logger settings remotely, receive email alerts of alarm conditions, link sensors from multiple sites into one account and assign multiple user privileges. Use the FilesThruTheAir App for Android for true on-the-go monitoring.

The software installed on the PC will allow set-up, data logging and data review. Set-up features will include sensor name, C/F, sample rate, and high/low alarms. Once configured, historic data can be viewed via the graphing tool or exported to Excel.

The sensor is IEEE 802.11b compliant, supports WEP, WPA/WPA2 encryption and enterprise networks.

* WiFi capability and integrated display* Wireless connectivity to PC via WiFi* Measurement range -40 to +125C (-40 to +257F)* Main unit IP43, probe IP67 * Rechargeable internal lithium polymer battery

Specifications

Power:Battery Life > 1 year*
USB supply voltage: 4.5V – 5.5V

* Typical, but will be less if frequent transmissions
Warning – do not exceed operating temperatures

Software:
Initial configuration of the data logger is done with Lascar’s EL-WIN-WiFi software running on Windows. Download the latest version of the control software or read more about connecting your WiFi device to the Cloud from the link below.

EasyLog WiFi Software
