WiFi Temperature Data Logging Sensor Plus – IC-EL-WIFI-T-PLUS

The EL-WiFi-T+ is a low powered battery device. When configured using typical transmission periods (e.g. once every 5 minutes) the sensor will operate for over one year (at room temperature). The battery can then be recharged via a PC or USB +5V wall adapter using the USB lead provided or can be permanently powered by the USB wall adapter.

Initial configuration of the data logger is done with Lascar’s EL-WIN-WiFi software running on Windows (compatible with 32-bit and 64-bit versions of Windows 7, 8 and 10). The EasyLog Cloud gives access to each data logger and data collected from any internet-enabled device including smartphone, tablet or computer. Change data logger settings remotely, receive email alerts of alarm conditions, link sensors from multiple sites into one account and assign multiple user privileges. Use the FilesThruTheAir App for Android for true on-the-go monitoring.

The software installed on the PC will allow set-up, data logging and data review. Set-up features will include sensor name, C/F, sample rate, and high/low alarms. Once configured, historic data can be viewed via the graphing tool or exported into Excel.
The sensor is a freestanding unit, however, it can be attached to a wall or vertical surface using the bracket and screws / sticky pad provided. The sensor is IEEE 802.11b compliant, supports WEP, WPA/WPA2 encryption and enterprise networks.

Features:
– WiFi capability and integrated display
– Wireless connectivity to PC via WiFi
– Temperature accuracy +-0.1C (-10 to +60C)
– Measurement range from -20 to +60C (-4 to +140F)
– Configurable high and low alarms with indicator
– Calibration certificate available

– Temperature measurement range: -20 (-4) to +60 (+140) C (F)
– Temperature measurement resolution: 0.01C
– Temperature display resolution: 0.01C
– Temperature accuracy: +-0.1 (-10 to +60C) to 0.15 (-20 to +60C)
– Battery life: 1 year
– USB supply voltage: 4.5 to 5.5 Vd.c.
– Operating temperature range (sensor only): -20 (-4) to +60 (+140) C (F)
– Logging period (user configurable): 10 sec/10 min/12 hrs
– Transmission period (user configurable): 1 min/1 hr/24 hrsSoftware:
Initial configuration of the data logger is done with Lascar’s EL-WIN-WiFi software running on Windows. Download the latest version of the control software or read more about connecting your WiFi device to the Cloud from the link below.

EasyLog WiFi Software
