Sale! RFPulse2000A Wireless Data Logger – IC-RFPulse2000A
- $438.99
- $98.00
Features:The RFPulse2000A calculates both pulse count and pulse rate. This feature allows the instrument to program engineering units into the device as a rate stat, providing more useful statistics for data logging over a prolonged period of time. It feat
- 100% Happiness Backed or Your Money Back
- Free Delivery on 30+ Orders
- 60-Day Hassle-Free Returns
Features:
The RFPulse2000A calculates both pulse count and pulse rate. This feature allows the instrument to program engineering units into the device as a rate stat, providing more useful statistics for data logging over a prolonged period of time.
It features an LCD screen which provides instant access to the current reading, minimum, maximum and average statistics. Through the software the device can be programmed to convert the pulse output into a different unit of measure such as gallons per minute or miles per hour. This information can be viewed on the LCD screen of the data logger as well as in the software.
The RFPulse2000A can be used as a standalone data logger, or used with the RFC1000 wireless transceiver, to wirelessly transmit data back to a central PC. The RFPulse2000A transmits up to 500 ft line of sight to the RFC1000 transceiver. Multiple RFC1000s can be used as repeaters and transmit up to 1000 ft line of sight to other RFC1000s. This allows the data to be sent back over a greater distance.
It can also be used as a single, wireless data logging system, or can be expanded to a large scale system, which can include hundreds of data loggers measuring a number of areas.
Specifications
| Pulse | |
| Maximum Pulse Rate | 10 KHz |
| Pulse Input Range | 0 to 4294967295 Pulses |
| Pulse Input Low | <720 mV |
| Pulse Input Hight | >1.070 V |
| Wireless | |
| RF Carrier Frequency | 2.45 GHz IEEE 802.15.4 ultra-low power MadgeNET Wireless |
| Transceiver with fully by-directional communication. | |
| Output Power | +0 dBm typical |
| Receiver Sensitivity | -95 dBm typical |
| Typical outdoors Line of sight | Up to 2000 ft |
| Typical Indoors line of sight | Up to 500 ft |
| General | |
| Memory | 65 Kilobytes (KB) |
| Reading Rate | 1 reading every second up to 1 reading every 24 hours |
| Baud Rate | 250,000 |
| Operating Environment | -20 C to +60 C (-4 F to +140 F), 0 %RH to 95 %RH |
| LED Indicators | Green, Blue & Red |
| Battery Life | 5 years typical at a 10 minute reading rate |
| Material | ABS plastic |
| Dimensions | 3.5 in x 3.0 in x 0.95 in (88.9 mm x 76.2 mm x 24.1 mm) |
| IP Rating | IP22 |
| Required Interface Package | RFC1000 |
| Approvals | US (FCC), CA (IC), CE, South Korea (KCC), China (CMIIT), Japan (LCIE) |
