1 kg Compact Digital Force Gauge with Data Output – IC-FG-3003

The new FG-3003 Series digital force gauge is the choice for simple, economical tension and compression testing. Combining a compact housing, yet maintaining a large back- lit LCD screen, it is designed to fit snug in the hand for ease of use. The multi-language FG-3003 provide menu programming for intuitive set-up of the instrument to your desired requirements.

Three modes of operation are available: Track mode displays live readings, Peak mode records the maximum values sensed during testing, and Pre-set mode, which activates user defined high and low limit set points. The programmable limits provide a fast visual and audible alert if a test passes or fails. Additionally, a comparator output enables integration of the instrument into your quality system for repetitive testing, for example production lines.
Features: – 1000 Hz Sample Rate combined with +/-0.3% F.S. accuracy provides fast sampling producing great resolution and more accurate results- Three mode operation: Track, Peak & Preset Limits- 180 degrees reversible display, tension/compression icons, and vertical printed keypad allows usage as a portable gauge or mounted upside down on a test stand- Programmable High & Low Limits allow for instant visual and audible indication of pass or fail testing in Preset mode- 500 point data collection capability can be viewed on display, sent to optional printer, or uploaded to software package for further analysis- Rugged, ergonomic die cast aluminum construction allows usage in demanding applications- Comparator output function provides user with easy Pass/Fail testing system integration capabilities- Multi-language and engineering unit’s selection provides flexible user options- Field Calibration capability eliminates the need to send to a lab for calibration- Factory Calibration Certificate included along with popular adapter attachments- Free Data logging/graphing software provided, sample rate up to 60 readings/sec

Specifications

– Accuracy: +/- 0.3% F.S.- Selectable Units: N, kgf, ozf, and lbf. (Depending on Range)- Overload Capacity: 150% of F.S. (LCD flashes beyond 110% of F.S.)- Measurement Method: Peak, Track, Preset- Data Sampling Rate: 1000 Hz- Display: 160 x 128 dot matrix LCD with Backlight- Display Update Rate: 10 times/second- Memory: 500 data- Set Point: Programmable high and low limits in Preset Mode- Power: 3.6VDC 800mAH Ni-MH rechargeable batteries- Battery Life: Approximately 16 hours continuous use per full charge- Charger/Adaptor: Universal USB/BM charger, Input: 110 ~ 240VAC- Temperature Effects: 0.03% FS per C- Outputs: USB, RS-232; High & Low Limit NPN’s- Operating Temperature: -10 to 40 C- Storage Relative Humidity: 20 to 80%- Housing: Aluminum- Dimensions: 140 x 71 x 35.5 mm- Product Weight: 400 grams- Warranty: 1-Year- Included Accessories: AC Adaptor/Charger, USB cable, calibration cert., 6 attachments: hook, flat tip, conical tip, chisel tip, notched tip, extension shaft

Warranty
1 Year Manufacturer Warranty + Additional 1 Year Instrument Choice Warranty
